Over the last few months, I've been heads-down on building the content for EpicWeb.dev. And I've been building it all in the open on my YouTube channel. If you've been watching my EpicWeb.dev live streams, you'll know that I've been building the app we'll use to learn web dev: Rocket Rental πŸš€. With that app, I've started with SQLite and I've been trying to decide whether I should move over to Postgres.

When I released the 2021 update to kentcdodds.com, I decided to use Postgres on Fly.io because of its support for multi-regional deploys and both Postgres and Redis clusters with automatic data replication (I use Redis for caching slow/rate limited third party APIs and expensive computations). That proved to work out really well. My site is fast wherever you are in the world. However, there are a few downsides:

  1. Databases are way outside my wheelhouse (and personal interest).
  2. Running my app locally requires starting up Postgres/Redis via docker compose which is fine, but annoying, especially for contributors.
  3. The infrastructure is complicated and can fail occasionally.

Also, when I built and deployed my site, I think I was the first to build and deploy a distributed Node.js app with a Postgres cluster on the Fly.io network. I believe the infra has improved, but I was still running on older versions of things and reliability was a problem (for both Postgres and Redis). I could definitely upgrade and improve those reliability concerns, but I had another idea. My site gets enough regular traffic that these reliability issues led to me getting a lot of tweets like this:

So I've been wanting to address these issues, but because I'm heads-down on EpicWeb, I didn't know how I could justify spending time on my personal site.

Whelp, I started the "Rocket Rental" app with SQLite to keep things simple and I'd really like to keep that if possible. At the same time, it's important to me that the app I use to teach web development is realistic. So I was expecting that eventually I'd move to "a real database" like Postgres. But I've been hearing rumblings about SQLite being pretty dang capable, so I decided to take advantage of my personal site's database reliability issues to spend time investigating SQLite's feasibility for use in my site.

Litestream

Several months ago, I met Kurt (Fly.io CEO) at Remix Conf. We talked about a new project he's been very excited about that I'd heard rumblings about called Litestream. He suggested that for many categories of applications, SQLite can provide an even better user experience than Postgres along with a simplified developer experience. Whenever I hear "better UX and DX," I'm interested.

Litestream was originally created to improve reliability of SQLite in edge cases (specifically, disaster recovery), but the way this was done also lends itself well to the idea of distributed SQLite deployments.

Turns out by the time Kurt and I had our conversation, he'd already hired Ben Johnson (the author of Litestream) to work at Fly. Ben wrote an awesome article explaining what Litestream is. I recommend you give it a read if you're unconvinced that SQLite is production-ready. He'll convince you it is.

LiteFS

Litestream has had "read-replicas" as a desired future feature for over a year. Ben joined Fly to work on that and has now released LiteFS. Architecturally, LiteFS works similarly to Postgres clusters. One LiteFS node is the "primary" and other nodes automatically replicate data writes. LiteFS acts as a proxy to your SQLite database (you connect to LiteFS instead of the underlying database) and then LiteFS effectively replays data updates to all read replicas. And this reply happens behind the scenes normally within 200ms (on par with distributed Postgres clusters).

LiteFS allows us to get distributed SQLite. As a reminder, the benefit of distributed databases is that the data for your app can be geographically close to the users of your app leading to hundreds of milliseconds performance boost (per request) for many users.

Additionally, SQLite data access is much faster than Postgres which is "fast enough" normally, but actually means SQLite suffers much less from N+1 queries (which should be avoided, but this is nice).

So with LiteFS, our users get a faster app because we get faster data access that's distributed all over the world. And on top of that, it's simpler thanks to the fact we don't have to manage a database server.

Evaluating the existing data

So, with that, I realized that it's possible for me to migrate to SQLite on my site without giving up the distributed nature of my app. Luckily for me, LiteFS is still in beta at Fly, so the migration went off without a hitch of course (jk jk, I felt the beta nature of things pretty hard πŸ˜…).

My existing app has the following Postgres data model:

datasource db {
  provider = "postgresql"
  url      = env("POSTGRES_DATABASE_URL")
}

generator client {
  provider = "prisma-client-js"
}

enum Role {
  ADMIN
  MEMBER
}

enum Team {
  BLUE
  RED
  YELLOW
}

model User {
  id           String     @id @default(uuid())
  createdAt    DateTime   @default(now())
  updatedAt    DateTime   @updatedAt
  email        String     @unique(map: "User.email_unique")
  firstName    String
  discordId    String?
  convertKitId String?
  role         Role       @default(MEMBER)
  team         Team
  calls        Call[]
  sessions     Session[]
  postReads    PostRead[]
}

model Session {
  id             String   @id @default(uuid())
  createdAt      DateTime @default(now())
  user           User     @relation(fields: [userId], references: [id], onDelete: Cascade)
  userId         String
  expirationDate DateTime
}

model Call {
  id          String   @id @default(uuid())
  createdAt   DateTime @default(now())
  updatedAt   DateTime @updatedAt
  title       String
  description String
  keywords    String
  user        User     @relation(fields: [userId], references: [id], onDelete: Cascade)
  userId      String
  base64      String
}

model PostRead {
  id        String   @id @default(uuid())
  createdAt DateTime @default(now())
  user      User?    @relation(fields: [userId], references: [id], onDelete: Cascade)
  userId    String?
  clientId  String?
  postSlug  String
}

By far, the largest table in my database is the PostRead table with nearly a half million rows. This actually blows my mind because that measures actual reads of my blog posts, not just page loads. Anyway, there are several thousand user and session rows and very few call rows (though those hold a lot of data).

The amount of data is important because the first thing I needed to think about was how to migrate the data. There are various established practices for doing this. I'm not a database guy, so I'm not well versed in them, but I considered one approach: Run both databases at the same time and write to both of them, writes go to both while still reading from the old one, then switch to reading from the new one and take down the old one... That sounded... annoyingly difficult. And unnecessary for my situation. But I did explore it for a while. It's probably what you'd want to do to ensure you had absolutely 0 data loss in the time it takes to move users to the new version of the app.

In my case, I was ok with a tiny bit of data loss. All that would be lost would be the data collected and changed in the Postgres database after I copied everything over to SQLite. I planned on doing the switch over as a DNS switch immediately after copying over the database so hopefully that would be a pretty short time.

We'll talk more about how I actually migrated the data itself later.

Updating App code

With that established, I needed to migrate my application from Postgres to SQLite. Luckily, because I use Prisma, this was pretty simple! Here's the diff to the schema file:

datasource db {
  provider = "postgresql"
  provider = "sqlite"
  url      = env("DATABASE_URL")
}

...

enum Role {
  ADMIN
  MEMBER
}

enum Team {
  BLUE
  RED
  YELLOW
}

model User {
  id           String     @id @default(uuid())
  createdAt    DateTime   @default(now())
  updatedAt    DateTime   @updatedAt
  email        String     @unique(map: "User.email_unique")
  firstName    String
  discordId    String?
  convertKitId String?
  role         Role       @default(MEMBER)
  team         Team
  role         String     @default("MEMBER")
  team         String
  calls        Call[]
  sessions     Session[]
  postReads    PostRead[]
}

...

I had to turn enum types into strings due to SQLite's lack of support for enums. Other than that, all I had to do was switch from postgresql to sqlite in the provider and everything else just worked for the schema.

Of course, this impacted my application a bit due to my reliance on those enums. I know prisma is working on a feature called "extensions" that would probably allow me to hook into prisma to do runtime checks to turn those columns into enums (effectively) so I wouldn't have to update any app code, but I'd rather not use that experimental feature just yet. So instead, I wrote a few handy types and utility functions:

type Team = 'RED' | 'BLUE' | 'YELLOW'
type Role = 'ADMIN' | 'MEMBER'
type OptionalTeam = Team | 'UNKNOWN'

const teams: Array<Team> = ['RED', 'BLUE', 'YELLOW']
const roles: Array<Role> = ['ADMIN', 'MEMBER']
const isTeam = (team?: string): team is Team => teams.includes(team as Team)
const isRole = (role?: string): role is Role => roles.includes(role as Role)
const getTeam = (team?: string): Team | null => (isTeam(team) ? team : null)
const getOptionalTeam = (team?: string): OptionalTeam =>
  isTeam(team) ? team : 'UNKNOWN'

With that, I just followed TypeScript squiggly lines to fix a few places that were busted (huzzah for TypeScript).

Database connections

The next thing that added complexity to my setup is updating how the database connects. To understand why this is so complicated, you need to understand a bit of the constraints there are with multi-region databases.

In my Postgres app, my primary region was Dallas (dfw). Let's say you're in Amsterdam (ams) and you want to update your first name in your KCD profile. When that POST request comes in, I automatically send a special kind of response with a header: fly-replay: dfw. Fly will intercept that response before sending it to you and "replay" that request to the node app running in Dallas.

It does this because the read replicas in all regions other than the primary region are unable to accept write requests.

Doing this is simple enough because I'm using express so I just have a simple middleware to do this for me. Unfortunately I do need to make data writes on non-POST requests. For example, I like to update your SESSION if you make a request within 6 weeks of your session's expiration so you don't have to re-authenticate if you're a regular reader of the post. In that case, I have two options:

  1. Write to the primary region directly (even though you're not in the primary region)
  2. Send a fly-replay response so it can be handled by the primary region

At the time I was working on my site originally, option 2 was very difficult. So I went with option 1. So every region created two Prisma clients: One called prismaRead (which connected to the local region db) and the other called prismaWrite (which connected to the primary region db). This worked just fine.

Unfortunately, with this migration to SQLite, option 1 is no longer possible. SQLite literally only runs locally on the machine and can't be connected to from the outside world. So now I have new options:

  1. Create special endpoints in my application so ams can call dfw to perform these specific writes.
  2. Send a fly-replay response so it can be handled by the primary region

I started with option 1 and I almost finished with it. It wasn't really complex or anything, but it sure was annoying. Then I remembered that when I was writing my site originally, we didn't have the throw Response feature in Remix. In Remix, at any point in your action or loader, you can throw a Response object and Remix will catch that and send the response. This made option 2 much easier. Had we been able to do this before, I would have gone with this option originally!

So, I made a util file for interacting with fly:

import fs from 'fs'
import os from 'os'
import path from 'path'
import invariant from 'tiny-invariant'

export async function ensurePrimary() {
  const {currentIsPrimary, currentInstance, primaryInstance} =
    await getInstanceInfo()

  if (!currentIsPrimary) {
    console.log(
      `Instance (${currentInstance}) in ${process.env.FLY_REGION} is not primary (primary is: ${primaryInstance}), sending fly replay response`,
    )
    throw new Response('Fly Replay', {
      status: 409,
      headers: {'fly-replay': `instance=${primaryInstance}`},
    })
  }
}

export async function getInstanceInfo() {
  const currentInstance = os.hostname()
  let primaryInstance
  try {
    const {FLY_LITEFS_DIR} = process.env
    invariant(FLY_LITEFS_DIR, 'FLY_LITEFS_DIR is not defined')
    primaryInstance = await fs.promises.readFile(
      path.join(FLY_LITEFS_DIR, '.primary'),
      'utf8',
    )
    primaryInstance = primaryInstance.trim()
  } catch (error: unknown) {
    primaryInstance = currentInstance
  }
  return {
    primaryInstance,
    currentInstance,
    currentIsPrimary: currentInstance === primaryInstance,
  }
}

export async function getFlyReplayResponse(instance?: string) {
  return new Response('Fly Replay', {
    status: 409,
    headers: {
      'fly-replay': `instance=${
        instance ?? (await getInstanceInfo()).primaryInstance
      }`,
    },
  })
}

With that, I could simply add ensurePrimary() in the few situations I needed to do a write on a GET request:

// if there's less than ~six months left, extend the session
const twoWeeks = 1000 * 60 * 60 * 24 * 30 * 6
if (Date.now() + twoWeeks > session.expirationDate.getTime()) {
  await ensurePrimary()
  const newExpirationDate = new Date(Date.now() + sessionExpirationTime)
  await prisma.session.update({
    data: {expirationDate: newExpirationDate},
    where: {id: sessionId},
  })
}

There really aren't many situations where a mutation on a GET makes sense so this works great. All the user experiences is a slightly longer response time in these rare scenarios.

With that in place, I was able to remove all the prismaWrite and prismaRead and just have a single prisma client. Ultimately this simplified things for me quite a bit.

To take things further, the fly team is currently working on making it so LiteFS will handle this all for me. They'll effectively allow writes to non-primary DBs. So hopefully in the near-ish future I can remove all this from my codebase. This will be a significant improvement. There's a trade-off here that I'll need to evaluate (I think it basically means that all writes are slow, even those to the primary region). Trade-offs everywhere!

Redis

Another thing I've been wanting to do is get rid of Redis. Remix uses SQLite to cache it's documentation pages and I realized I could do the same thing with my blog posts and third party APIs I cached. This would significantly simplify my architecture further by reducing the number of services my app depends on (Redis had definitely caused outages on my site as well).

When I built my site, I created an abstraction for turning a function into a "cachified" version of itself called... wait for it... cachified. Hannes Diercks asked whether he could extract my code for that and package it up as a library. I said yes and here it is. So I decided to take this opportunity to delete my own implementation and use Hannes' improved library.

At first, I planned on just adding a Cache table to my SQLite database as part of my prisma schema. But then I realized that I would run into issues with not being able to write to the cache in non-primary regions. Replaying requests to do this would kind of defeat the purpose of the cache (which is to make things faster), so I decided to use a separate SQLite database for the cache. Thanks to better-sqlite3 (which is COMPLETELY SYNCHRONOUS!), this was pretty simple.

For the most part, moving from my own cachified to Hannes' version went very well. There were just a few different (better) option names and I needed to write a SQLite adapter:

export const cache: CachifiedCache = {
  name: 'SQLite cache',
  get(key) {
    const result = cacheDb
      .prepare('SELECT value, metadata FROM cache WHERE key = ?')
      .get(key)
    if (!result) return null
    return {
      metadata: JSON.parse(result.metadata),
      value: JSON.parse(result.value),
    }
  },
  set(key, {value, metadata}) {
    cacheDb
      .prepare(
        'INSERT OR REPLACE INTO cache (key, value, metadata) VALUES (@key, @value, @metadata)',
      )
      .run({
        key,
        value: JSON.stringify(value),
        metadata: JSON.stringify(metadata),
      })
  },
  async delete(key) {
    cacheDb.prepare('DELETE FROM cache WHERE key = ?').run(key)
  },
}

Now I can ditch another service and simplify my architecture even further! One drawback to this, however is that I don't get auto-replication like I did when using Redis (fly managed that for me). So each region has to manage its own cache which is not a huge deal, but it's something to keep in mind. Maybe one day when LiteFS supports writing to all regions, I'll move this into LiteFS as well.

The double-thick wall

Unfortunately, I hit a bit of a wall once I finished this part of the migration. MDX pages wouldn't display. Anything that used MDX wouldn't work at all. This meant not only blog posts or mdx pages, but also any page that has blog post recommendations (so most pages). It took me quite some time debugging this to figure out that MDX compilation was causing me trouble because there were actually two problems and one of them only happened when deployed to my staging environment 😱

The first issue was I happened to be using the same cache key for two functions πŸ™ˆ For various reasons I don't want to get into, they actually do end up storing the same data. The reason this migration to the new cachified package broke this is because the cachified library does a good job of making sure you only get a fresh value for a particular key once and all other requests for it wait on that first one. So I ended up getting into a situation where Function A would trigger getting a fresh value which called Function B which asked for that same key in the cache so it hung forever.

If that's confusing, it's because it was. Don't worry, it's not important that you understand the problem. Just know this. When dealing with a cache, make sure to not share a cache key between two different places that can create the cached value.

The second issue was extremely frustrating because I couldn't reproduce it locally. This meant I had to deploy my site to make and view changes. I couldn't use my preferred debugging tools (I could only use console.log and watch the logs). I made use of patch-package to add logs to libraries I was using. I added a crazy number of logs to @remix-run/server-runtime only to determine that it was working perfectly.

I added a resource route to the app so I could run only the offending code (to reduce logs and just because this is typically a good practice during debugging to scope down the search area). I eventually found that the issue lay in MDX compilation again. I added logs to mdx-bundler and found that execution stopped when starting to actually compile the MDX with esbuild.

Finally I realized it was a very specific blog post that caused the hold up. It was my "Migrating to Jest" blog post. I realized I needed to figure out what part of that post was causing issues. So I updated my GitHub fetching code so it could fetch from the correct branch (so I could make content changes in the dev branch and not main where people would be confused about my experiments in production). With that in place, I chopped up the post into 10 sections. Each had a part of the post.

I hit the special resource route for each of those sections. I found it was in the last section. I further split that into 6 more sections and found the problem was a specific tweet. The tweet at the end of the post where I said: "PayPal is hiring!" which also linked to a PayPal job listings page that is no longer working. My custom twitter embed remark plugin performs a GET request to links within tweets so I can display metadata like the title/description/image for the page. Unfortunately because the page wasn't working (it just hangs forever), it caused compilation to hang forever which caused most pages on my site to hang forever as well.

Phew! What a pain! So I added a timeout for compilation and I removed the tweet from the post. There's probably more I could do to improve the resilience of this code as well πŸ˜…

Deploying LiteFS

With that bug worked out, my site was humming along just fine in a single region. So I was ready to figure out how to setup LiteFS to get multi-region working.

Because LiteFS is still in beta, documentation is still relatively sparse. Even worse, somehow I missed all but the example documentation page. So I was stumbling around in the dark quite a bit. Finally I figured out which files I needed and where. I got help from Ben directly in a Zoom call during one of my streams. I did bump into a number of issues that went back as feedback to the Fly team. Ben was quite responsive and helpful. I finally did get it working though.

One thing I love about LiteFS is that it doesn't infect my app code all over the place. The only thing I need to worry about is that read replicas are read-only (for now), so I have to do the fly-replay stuff. Really looking forward to when I won't have to even do that and it really will just be a bit of configuration that doesn't impact my app code one bit.

The Migration

I had my app working in a staging environment for a while. Once I felt like that was working well in multiple regions I decided to start the migration. So I put together a little list of things I needed to do:

  1. Open up logs on everything
  2. Double-check volumes in kcd (den is primary)
  3. Double-check memory allocation in kcd (use 2GB during migration, can drop to 1GB later)
  4. Double-check env vars in kcd
  5. Merge to main - trigger a deploy
  6. Prepare DNS switch (don't run it)
  7. SSH into the server and run npx /app/prisma-postgres/migrate.ts
  8. Quick Manual Quality check
  9. Run DNS switch
  10. Pray
  11. Add new regions (fly vol create --size 3 -a kcd --region {ams,maa,syd,gru,hkg}) and scale (fly scale count -a kcd 6)
  12. Make sure writes in non-primary regions are working
  13. Delete prisma postgres stuff (the migrate script and stuff in the dockerfile)
  14. Enable workflow quality control (turn back on ESLint, TypeScript, Testing, etc.)

Everything went great. As I write this, I'm running the migration script. Turns out, with almost half a million records, using a naΓ―ve approach to migration takes quite some time. It would probably be much faster if I were smarter with databases, but here's what my script did:

import {PrismaClient as SqliteClient} from '@prisma/client'
// eslint-disable-next-line import/no-extraneous-dependencies
import {PrismaClient as PostgresClient} from '@prisma/client-postgres'

// TIP: do not do this if you have lots of data...
async function main() {
  const pg = new PostgresClient({
    datasources: {db: {url: process.env.POSTGRES_DATABASE_URL}},
  })
  const sq = new SqliteClient({
    datasources: {db: {url: process.env.DATABASE_URL}},
  })
  await pg.$connect()
  await sq.$connect()

  console.log('connected πŸ”Œ')

  await upsertUsers()
  await upsertSessions()
  await upsertPostReads()
  await upsertCalls()

  console.log('βœ…  all finished')

  await pg.$disconnect()
  await sq.$disconnect()

  async function upsertUsers() {
    console.time('users πŸ‘₯')
    const users = await pg.user.findMany()
    console.log(`Found ${users.length} users. Upserting them into SQLite ‴️`)
    for (const user of users) {
      // eslint-disable-next-line no-await-in-loop
      await sq.user.upsert({where: {id: user.id}, update: user, create: user})
    }
    console.timeEnd('users πŸ‘₯')
  }

  async function upsertSessions() {
    console.time('sessions πŸ“Š')
    const sessions = await pg.session.findMany()
    console.log(
      `Found ${sessions.length} sessions. Upserting them into SQLite ‴️`,
    )
    for (const session of sessions) {
      // eslint-disable-next-line no-await-in-loop
      await sq.session.upsert({
        where: {id: session.id},
        update: session,
        create: session,
      })
    }
    console.timeEnd('sessions πŸ“Š')
  }

  async function upsertPostReads() {
    console.time('postReads πŸ“–')
    const postReads = await pg.postRead.findMany()
    console.log(
      `Found ${postReads.length} post reads. Upserting them into SQLite ‴️`,
    )
    for (let index = 0; index < postReads.length; index++) {
      if (index % 100 === 0) {
        console.log(`Upserting ${index}`)
      }
      const postRead = postReads[index]
      if (!postRead) {
        console.log('HUH??? No post read??', index)
        continue
      }
      // eslint-disable-next-line no-await-in-loop
      await sq.postRead
        .upsert({
          where: {id: postRead.id},
          update: postRead,
          create: postRead,
        })
        .catch(err => {
          console.error('error', err, postRead)
        })
    }
    console.timeEnd('postReads πŸ“–')
  }

  async function upsertCalls() {
    console.time('calls πŸ“ž')
    const calls = await pg.call.findMany()
    console.log(`Found ${calls.length} calls. Upserting them into SQLite ‴️`)
    for (const call of calls) {
      // eslint-disable-next-line no-await-in-loop
      await sq.call.upsert({where: {id: call.id}, update: call, create: call})
    }
    console.timeEnd('calls πŸ“ž')
  }
}

main().catch(e => {
  console.error(e)
  process.exit(1)
})

There's more interesting stuff that happened here. If you're interested in watching the migration, then tune in here.

The whole thing took about an hour and fifteen minutes to run the migration script. But once that was finished, everything else went off pretty much without issue.

To be continued

"Went off pretty much without issue" that is... Until I tried deploying to new regions... More to the story later. I'm still working through this.

Conclusion

Only time will tell whether this was a good idea or not. I'm pretty confident that it will be. Just moving from three services to one is quite nice. Local development is simpler thanks to just using SQLite as well.

And I'm hopeful that the site will be noticeably faster. I may add real numbers to this section of the post once the new site gets some more traffic.

Kent C. Dodds
Written by Kent C. Dodds

Kent C. Dodds is a JavaScript software engineer and teacher. Kent's taught hundreds of thousands of people how to make the world a better place with quality software development tools and practices. He lives with his wife and four kids in Utah.

Learn more about Kent

If you found this article helpful.

You will love these ones as well.
